Field proven under the toughest bridge conditions everywhere in the world, the Wabo®Modular joint system is made to order in accordance with the highest fabrication standards and can be engineered to meet a variety of conditions and movement requirements.
Wabo®Trident Finger Joint system expands the use and application of finger joint technology. A strategically designed plurality of finger plates and support mechanism accommodates transverse and vertical bridge deck movements. Each trident finger assembly is pre-tensioned, and elastomeric support bearings create a noise-free, smooth riding surface.
The Wabo®ElastoFlex (EFL) - The Bridge Series joint system is a construction solution designed for bridge joints. It incorporates high-quality elastomeric materials, featuring a continuous gland made of fabric-reinforced EPDM rubber. This glad is securely locked by modular steel-reinforced EPDM anchor blocks, ensuring robust construction. The ends of each anchor block tongue and grooved together to ensure a positive connection and prevent uplift or separation. The membrane gland which is installed continuously curb to curb has a total movement capability of 4 inches.
Our Mixing Paddle is perfect for getting the best mix to your Wabo®Crete II and ElastoPatch headers.
Wabo®Finger Joint cantilevered system sets the benchmark for the use and application of finger joint technology. Single direction of movement ranging from 4 to 18". Simple one piece/ full length factory assembled allows for quick installation. Enhanced system functionality and installation experience by adding a neoprene gutter trough or bulkhead form.
The Wabo®X-cel Modular is an expansion joint specifically designed to accommodate structural movements in all directions. This system will satisfy thermal, high velocity, and multi-directional movement requirements for both seismic and/or multi-directional movement applications. The Wabo® X-cel Modular is the product of a ten year research and development program, during which full scale dynamic performance tests were conducted at the University of California/ Berkeley PEER Center.
Wabo®Non-Flow Additive is used with Wabo®Crete II elastomeric concrete in sloped conditions, to slow the flow of material.
Wabo®FingerPlus patent pending finger joint system expands the use and application of finger joint technology. Single direction of movement ranging from 6 to 24”. The 6’ sections make for a simple modular installation, an ideal fit for staged construction. Segmental finger construction allows easy maintenance of all components from the bridge deck with minimizing interruption of traffic flow. Optional features help to enhance the system maintenance and installation experience.
The Wabo®StripSeal system is a unique concept for effectively sealing expansion joints in bridges and structures. Elastomeric seals lock into a machined steel cavity for a watertight connection.
Wabo®Bonding Agent is used to seal out moisture prior to installation of Wabo®Crete II.
Wabo®PrimaLub Adhesive is used to install elastomeric profiles and enhance watertightness between profile and adjoining substrate or metal.
Bridge Expansion Joint System (BEJS) is a traffic-durable bridge and roadway expansion joint which provides a primary watertight seal. The system is comprised of a pre-compressed, silicone-and-foam hybrid installed into field-applied epoxy adhesive on the joint faces, with the silicone bellows locked to the joint faces with a silicone sealant band. The BEJS SYSTEM features a hydrophobic acrylic impregnation infused into the cellular foam base material resulting in low-temperature flexibility not available in asphalt, wax, or isobutylene-based products.
WaboCrete® II is a highly capable, two-component polyurethane header with a specialty aggregate, 100% solids material for use in exterior construction environments. WaboCrete® II absorbs traffic impact loads and evenly disperses them into the deck, while allowing the system to flex with deck loads. It is resistant to ozone, deicing chemicals, and even harsh abrasives.
The Wabo®Expandex system is a unique expansion joint for asphalt overlays and abutment joints. The system is a one piece monolithic asphaltic plug joint designed to eliminate the need for any anchoring device and provide a flexible yet smooth ridging joint.
Wabo®GutterFlex is a flexible fabric reinforced neoprene profile that satisfies the required movement criteria and compresses without damage during the full cycle of joint closure. The system collects and drains excess amounts of moisture through a optional drain tube that exhibits similar flexibility. The block out or under slab versions can be used as a secondary back up to any expansion joint system in today’s marketplace.
The Wabo®SPS expansion joint system is a preformed silicone joint sealing system designed to accommodate movements and varying joint widths on bridges and other civil structures requiring watertightness of expansion joints. Ideally suited for both new construction and retrofitting of existing expansion joints, the Wabo®SPS system is a durable quick turn around solution for sealing deck joints.
Wabo®SurfaceMend is a two (2) part specially formulated polymer concrete system designed for use in exterior applications on bridges and airports. When mixed with our proprietary aggregate, the impact resistance and flexibility of this product’s high tensile elongation is combined with industry leading compressive strength to provide impressive durability for the most demanding applications.
Wabo®Sil Adhesive is a one-component silicone adhesive used to install Wabo®SPS and Wabo®Crete SPS Systems.
Wabo®Bonding Agent is used to seal out moisture prior to installation of Wabo®Crete II. View Technical Datasheets
Wabo®Foam Seal Bonder is a 100% solids, two component moisture-insensitive modified epoxy adhesive which meets ASTM C-881 Type I and II Grade 2 Class B&C.
Wabo®Paste Adhesive (Cold Weather) is used to install Jeene® and Wabo®InverSeal at temperatures between 40 and 60 degrees F
Emcrete II by Emseal is a flexible, rapid setting, self-leveling, impact absorbing elastomeric concrete exclusively for bridge and DOT applications. It is a non-hazardous, extremely-low VOC product primarily used filling blockouts, impact-absorbing backfill nosing, patching potholes, or spalls on concrete roadways and bridges. Rapid curing means you can usually install expansion joint systems into an Emcrete II joint header after about 45-minutes. You can turn traffic to Emcrete II used either as patch or as an expansion joint header in 2-3 hours.
Epoxy bonded Seal is a continuous, extruded seal that is bonded into place with a two-component 100% solids adhesive. It is designed to create a watertight seal where water and debris will not enter occupied space below the joint opening under designed movement range.
Wabo®ElastoPatch is an ambient-cured unique modified elastomeric concrete material for repair of random cracks and spalls in existing Portland cement concrete pavement. Wabo®ElastoPatch is resistant to wear under repetitive loadings and chemical attack in harsh environments. The superior bonding capabilities to concrete minimizes edge spalling associated with high impact loads.
Wabo®Flex is a molded rubber segmental expansion joint designed to accommodate structure movements from 2 inches up to 13 inches. The Wabo®Flex system consists of molded rubber segments which are steel reinforced and embedded with corrosion-resistant aluminum wear plates. Tongue and grooves at the end of each rubber segment, prevent uplift or separation while ensuring a watertight connection.
The Wabo®MDM TransFlex is a unique multi-directional movement (MDM) segmental plate expansion joint assembly designed to accommodate large differential displacements, rotations and service movements as well as seismic movements. The simplistic design of the assembly is comprised of four main design components: the deck plate, the elastomeric segmental panels, the support plate and the welded channel/box assembly. Unlike other large movement capacity expansion joint technologies, Wabo®MDM TransFlex shifts the expansion component away from the critical joint opening and onto the deck surface. This shift increases the service life of the elastomeric segmental panels.
Wabo®SiliconeSeal is a dynamic, high performance; two-part silicone sealant designed for a variety of bridge expansion joint applications. The self-leveling, rapid cure of the Wabo®SiliconeSeal is ideal for joints where anticipated movements are +100%/- 50% of the joint opening.
Wabo®TransFlex is renowned as the original-reinforced elastomeric molded rubber expansion joint system and stands as a top choice for bridge joints. Its rubber modules are not only steel-reinforced but also ingeniously designed with tongue and groove fittings, ensuring a snug, end-to-end mating, both across decks and at curbs. This Transflex bridge solution is suitable for installation in new decks or as part of rehabilitation projects in older structures. All models adapt readily to skew angles. Properly installed, the Wabo®TransFlex system will accommodate anticipated thermal movements reject debris, and create a level, smooth-riding, wear-resistant surface.
PP Primer is used to create and enhance bond between like Santopreme profiles. Use with Aron Alpha 241F Adhesive.
Wabo®Concrete Cleaner is used to clean concrete prior to installation of Jeene® or Wabo®InverSeal.
Wabo®Neo-Lube Adhesive is a one component blend of neoprene and aromatic solvents used to insert and bond seals to concrete or metal surfaces. The material meets or exceeds ATSM D2835 and complies with ASTM D2628 and AASHTO M220.
Jeene® - Bridge Series is a structural sealing joint system comprised of a neoprene profile, which is air-pressurized and bonded in place with a specially formulated epoxy adhesive. When properly installed, the high performance Jeene® joint system will not tear away, protrude out of, or slip from its original position when exposed to repeated mechanical or thermal movements.
Wabo® brand CompressionSeals have been perfected over their 30-year history of successful installations in parking structures, athletic facilities and general horizontal applications.
Wabo®Evazote UV is preformed low density closed cell joint seal that is bonded into place with a two component 100% solids modified epoxy adhesive. Wabo®Evazote has a working movement range of 60% compression, 30% tension and 120% shear. The UV stability of Wabo®Evazote allows the seal to be resistant to abrasion, oxidation, oils, salt and other materials that are spilled on or applied to the surface. Add To Submittal
Wabo®FS Bridge Seal is a pre-compressed, foam-supported silicone bridge joint system. The Wabo®FS Bridge Seal is comprised of a 100% acrylic impregnated polyurethane foam seal coated with a highway grade UV Stable silicone. The foam seal is designed to be permanently bonded to the joint substrate with a user-friendly field applied Wabo®Gel Adhesive.
The Wabo®SPS CALTRANS Bonded Joint Seal expansion joint system is a preformed silicone joint sealing system designed to accommodate movements and varying joint widths on bridges and other civil structures requiring watertightness of expansion joints. Ideally suited for both new construction and retrofitting of existing expansion joints, the Wabo®SPS system is a durable quick turn around solution for sealing deck joints.
Wabo®SafetyFlex is an elastomeric hinged cover system that is ideal for pedestrian walkway areas as well as in low-speed vehicular traffic areas, including bridges. Loading-bearing, independent metal plates integral to the molded rubber cover allows the system to flex in response to changes in vertical displacement between opposing slabs. Used in both recessed and surface mount applications.
Wabo®XPE is a preformed, impermeable, UV stable gray foam joint seal that is bonded into place with a two component 100% solids modified epoxy adhesive. Wabo®XPE has a working movement range of 60% compression and 30% tension. The Wabo®XPE Seal is resistant to abrasion, oxidation, salts and other materials that are spilled on or applied to the surface.
PP Primer S is used to create and enhance bond between Santoprene profiles and unlike substrate materials such as aluminum.
Wabo®Conditioning Agent is used to prepare Jeene® or InverSeal profile for epoxy bonding to substrate
The Wabo®Gel Adhesive Gun pneumatic gun used for the application of Wabo®Gel Adhesive.
Wabo®GelAdhesive is a rapid curing, epoxy based, gel adhesive used to bond rubber seal and foam based products to concrete and steel substrates. The product is packaged in side by side cartridges, which allows the product to be mixed via a static mixing tip and applied with a dual cartridge application gun.
Our Wabo®Pogo Stick is used to install Wabo®Compression Seal product.
