Sikaflex®-2C NS TG+

TRAFFIC-GRADE ADDITIVE FOR SIKAFLEX®- 2C NS EZ MIX+

Sikaflex®-2C NS TG+ is a premium-grade, polyurethane-based, additive for use in Sikaflex®-2C NS EZ Mix + sealant. It is principally an additive that helps cure the sealant with a higher Shore A hardness for use in Traffic Grade applications in a non-sag consistency.    When mixed with Sikaflex®-2C EZ MIX +, it is available in 35 standard colors (> 320 special colors) with a convenient Colorpak. Also available as a pre-pigmented product in Limestone Gray. Meets ASTM C 920, Type M, Grade NS, use T, NT, O, M, G, A, and Federal Specification TT-S-00227E.

When used with Sikaflex®-2C NS EZ Mix + is
  • Capable of ± 35 % joint movement.
  • Chemical cure allows the sealant to be placed in joints exceeding 1/2 inch (25.4 mm) in depth.
  • Tough, durable, flexible consistency.
  • Exceptional cut and tear resistance Exceptional adhesion to most substrates without priming.
  • Color uniformity assured via Color-pak system or pre-pigmented Limestone.
  • No Color-pak needed in pre-pigmented Limestone.
  • Jet fuel resistant.
Product Data Sheet Show all documents

Usage

  • Applications to include: parking garages, walkways, plazas, platforms, etc., with exposure to foot or pneumatic-tire traffic
  • Intended for horizontal joints with a minimum depth of 1/2 in. (12.7 mm)
  • Placeable at temperatures as low as 40 °F (4 °C) Adheres to most substrates commonly found in construction


Advantages

When used with Sikaflex®-2C NS EZ Mix + is
  • Capable of ± 35 % joint movement.
  • Chemical cure allows the sealant to be placed in joints exceeding 1/2 inch (25.4 mm) in depth.
  • Tough, durable, flexible consistency.
  • Exceptional cut and tear resistance Exceptional adhesion to most substrates without priming.
  • Color uniformity assured via Color-pak system or pre-pigmented Limestone.
  • No Color-pak needed in pre-pigmented Limestone.
  • Jet fuel resistant.

Packaging

1 pint cans (6 cans per carton)

Color

Clear additive, when Sikaflex®-2C NS TG+ mix with Sikaflex®-2C NS EZ Mix + a wide range of architectural colors are available. Special colors available on request

Product Details

Product Information

Shelf Life

12 months in original, unopened containers

Storage Conditions

Store dry at 40–95 °F (4–35 °C). Condition material to 65–75 °F (18–24 °C) before using
Technical Information

Testing

40 ± 5               (after 21 days at 73 °F (23 °C) and 50 % R.H.) (ASTM C-661)

Tensile Strength

170 psi             (after 7 days at 73 °F (23 °C) and 50 % R.H.) (ASTM D-412)

Tear Strength

< 35 lbf/in          (after 7 days at 73 °F (23 °C) and 50 % R.H.) (ASTM D-624)

Movement Capability

± 35 %

Resistance to Weathering

Excellent

Elongation at break

580 %                (after 7 days at 73 °F (23 °C) and 50 % R.H.) (ASTM D-412)

Application

Application Information

Ambient Air Temperature

40 °F to 100 °F

Sealant should be installed when joint is at mid-range of its anticipated movement.

Substrate Temperature

40 °F to 100 °F

Sealant should be installed when joint is at mid-range of its anticipated movement.

Application Time

Sikaflex®-2C NS TG+ with Sikaflex®-2C EZ Mix +

3 hours at 73 °F
Consumption

Coverage

1 gallon of Sikaflex®-2C NS EZ Mix + & Sikaflex®-2C NS TG+: Yield in Linear feet

Width/Depth

1/4''

3/8''

1/2''

1/4''

307.9

3/8''

205.3

136.8

1/2''153.9102.677.0
3/4''102.668.451.3
1''38.5
1.25''30.8
1.5''25.7
Application steps

SUBSTRATE PREPARATION

All joint-wall surfaces must be clean, sound, and frost free. Joint walls must be free of oils, grease, curing compound residues, and any other foreign matter that might prevent bond. Ideally, this should be accomplished by mechanical means. A roughened surface will also enhance bond. Bond breaker tape or backer rod must be used in bottom of joint to prevent bond.



Priming

Priming is typically not necessary. Most substrates only require priming if sealant will be subjected to water immersion after cure. Testing should be done, however, on questionable substrates, to determine if priming is needed. Consult Technical Service or Sikaflex® Primer Technical Data Sheet for additional information on priming.

MIXING

Sikaflex®-2C NS TG+ must be used with Sikaflex®-2C NS EZ Mix +.

  • Pour entire contents of Sikaflex®-2C NS TG+ and Component ‘B’ into pail of Component ‘A’ of the Sikaflex®-2C NS EZ Mix +. For tint base: add entire contents of Color-pak into pail and mix with a low-speed drill (400–600 rpm) and Sikaflex® paddle.
  • Mix for 3-5 minutes to achieve a uniform color and consistency. Scrape down sides of pail periodically. Avoid entrapment of air during mixing.
  • For prepigmented limestone base: just mix with low speed drill and Sikaflex® paddle without Color-pak.

See Sikaflex®-2C NS EZ Mix + Product Data Sheet for detailed mixing instructions.
