Product Data Sheet
Show all documents
Sikalastic®-395 Textured

Sikalastic®-395 Textured

Textured Traffic Coating System

Sikalastic®-395 Textured is a three-component, chemically cured, elastomeric aliphatic polyurethane coating intended for use as the traffic bearing wear and top coat over Sikalastic® 390 polyurethane waterproofing membrane and over Sikalastic® 391 polyurethane intermediate wear coat for pedestrian and vehicular traffic bearing applications.

  • Low odor and fast turnaround
  • Excellent crack-bridging properties and flexibility, even at low temperatures
  • Outstanding resistance to abrasion and wear
  • Long term UV resistance
  • Resistant to deicing salts
  • Range of standard colors
Product Data Sheet
Show all documents

Usage

  • Multi-story parking garages
  • Parking decks and ramps
  • Foot bridges and walkways
  • Mechanical rooms
  • Stadiums and arenas
  • Plaza and rooftop decks
  • Balconies


Advantages

  • Low odor and fast turnaround
  • Excellent crack-bridging properties and flexibility, even at low temperatures
  • Outstanding resistance to abrasion and wear
  • Long term UV resistance
  • Resistant to deicing salts
  • Range of standard colors

Packaging

5 gal. 3 component kit, 4.5 gal. comp. A, 0.5 gal. comp. B, 10 lbs. comp. C

Color

Gray, Charcoal and Tan; custom colors available

Product Details

Product Information

Shelf Life

12 months in original, unopened containers

Storage Conditions

Store dry at 41–95 °F (5–35 °C). Condition material to 65–85 °F (18–30 °C) before using

Solid content by volume

100 %

(ASTM D-2697)

Volatile organic compound (VOC) content

< 10 g/l

(ASTM D-2369-81)
Technical Information

Shore A Hardness

85 +/- 5 (75 °F (24 °C) and 50 % R.H.)

(ASTM D-2240)

Abrasion Resistance

15 mg of loss

(75 °F (24 °C) and 50 % R.H.)

(ASTM D-4060, Taber Abraser,

CS-17 Wheel/1000 g (2.2 lb)/1000 cycles)

Tensile Strength

2500 +/- 300 psi (75 °F (24 °C) and 50 % R.H.)

(ASTM D-412)

Tear Strength

79 pli (75 °F (24 °C) and 50 % R.H.)

(Die C, ASTM D-624)

Chemical Resistance

Resistant to deicing salts

Application

Application Information

Pot Life

35–45 minutes
Consumption

Coverage

80 sf/gal. at 14 wet mils (14 dry mils)

70 sf/gal. at 16 wet mils (16 dry mils)

62 sf/gal. at 18 wet mils (18 dry mils)

Coverage rates provided are intended to achieve required wet film thickness under optimal conditions. Additional material may be required depending on substrate surface roughness and porosity, material , substrate and air  temperatures, and other site-dependent factors. This will result in a lower coverage rate.
Application steps

MIXING

Premix Part A and Part C components using a low speed (400–600 rpm) mechanical mixer and Jiffy Paddle at slow speed to obtain uniform color, making sure to scrape the solids and the aggregate from the bottom and sides of the pail.The aggregate should be evenly diffused in the resin. Pour part B into Part A+ C slowly and while mixing scrape the side of the container, Mix the combined material thoroughly until a homogenous mixture and uniform color is obtained (typically 3 minutes). Use care not to allow the entrapment of air into the mixture

APPLICATION

Wear coat: Apply at the recommended coverage rate 16 mils wet (70 sf/gal) using a 1/8”–3/16” notched squeegee or trowel, and backroll using nap roller 3/8” to uniformly backroll prior to applying topcoat. It should be backrolled two times, one perpendicular to the other.



Top coat: Apply at the recommended coverage rate 16 mils wet (70 sf/gal) using a 1/8”–3/16” notched squeegee or trowel, and backroll using nap roller 3/8” to uniformly backroll. The Top coat should be backrolled two times, one perpendicular to the other. Allow coating to cure a minimum of 4 hours at 70 °F and 50 % R.H.; coating must be tack free before overcoating.



Allow coating to cure for a minimum of 36 hours before opening to vehicular traffic.



Removal

Remove liquid coating immediately with dry cloth. Once cured, coating can only be removed by mechanical means.

Documents
