Sarnacol®-2163 Adhesive

• FM Global
• Underwriters Laboratories
• Miami-Dade County
• Florida Building Code

Liquid

18 months if stored properly in original unopened, sealed and undamaged packaging

Store in a dry location, not in direct sunlight, or temperatures higher than 90°F (32°C). Keep containers closed. Contamination by moisture or basic compounds can cause dangerous pressure build-up in a closed container

18 g/L (Part 1 + 2 Combined)

Can be applied at any temperature provided the product temperature is between 65°F (18°C) to 85°F (29°C) 24 hours prior to use

All surfaces must be clean, dry, and free of dirt, grease, oil, or other contaminants or particulates. All concrete surfaces must be cured prior to applying Sarnacol®-2163 Adhesive.

Use the handheld cartridge applicator. Remove the plastic plugs from the cartridge mixing head. Attach a mixing tip to the threaded mixing head. Place the cartridge into the applicator. When starting a new cartridge, dispense some adhesive into a bucket or other suitable receptacle to achieve a proper mix.

Apply Sarnacol®-2163 Adhesive directly to the substrate using a ribbon pattern. Apply adhesive in ¼ – ½'' (6 – 13 mm) wide wet beads. Ribbon spacing will depend on the wind uplift rating required.

As adhesive is applied, immediately place boards into wet adhesive. Walk boards in, ballast if necessary to achieve proper contact with substrate.

Unused adhesive can be applied at a later date by simply replacing the mixing tip.

COVERAGE
Application rates vary depending on surface roughness and absorption rate of the substrate. Typical coverage rate when using the 1.5 L cartridges is approximately 600 ft² (56 m²) per case. Rates are based on an application pattern of 4 ribbons, ¼ – ½" (6 – 13 mm) beads, 12'' (30 cm) o.c. per 4 ft x 4 ft (1.2 m x 1.2 m) insulation board.
